General Specs |
| Product Weight (lbs.) | 29.56 |
| Color | Black |
| Woofer Size | 10" |
| Speaker Type | Powered Subwoofers |
| Manufacturer Warranty | 5 Year |
| Collection | Bronze W10 |
| Color Finish Name | Black |
| Speaker Size | 10 |
| RMS Power Handling (Watts) | 220 |
| Subwoofer Size | 10" |
Additional Specifications |
| System Format | Long-throw 10" driver featuring ‘dished’ C-CAM cone. 10" flat panel ABR (Auxiliary Bass Radiator). |
| Lower Frequency Limit | -3 dB @ 33 Hz / -10 dB @ 28 Hz (Free Field) Default preset: Music, -3 dB @ 29 Hz / -10 dB @ 25 Hz (In Room) |
| Upper Frequency Limit | -6 dB @ 150 Hz |
| Drive Unit Complement | 1 x 250 mm (10") C-CAM subwoofer driver featuring a 2" long throw voice coil |
| Linear Driver Excursion | 17 mm peak to peak |
| Amplifier Output | 220 W |
| Amplifier Classification | Class D with high current Switch mode power supply (SMPSU) |
| Phase Control | 0 Degrees & 180 Degree pure Invert |
| Low Pass Filter Alignment | 4th order (24 dB/Octave), from 50 Hz to 120 Hz |
| Equalisation DSP | 3 pre-set modes: Music, Movie, Impact |
| Auto Sensing | Line Level >3mV. Auto Standby feature after 20 mins |
| Audio Input/Outputs | LFE unbalanced input RCA, Stereo unbalanced inputs RCA |
| Input Impedance | 20 kOhms input impedance |
| 12 V Trigger | 3.5 mm mono mini-jack. 6 V threshold |
| Electrical Certifications | CE / CB / ETL / Fcc / CCC / ErP (Energy saving compliant) |
| Mains Input Voltage | 100 – 120 Vac 50 – 60 Hz / 220 – 240 Vac 50 – 60 Hz (Manually selected) |
| Power Consumption | Maximum 300 W, Standby <0.5 W (ErP compliance) |
| Fuse Type | 20 mm T4AL 250 VAC |
| External Dimensions (Including Amp, Drivers and Terminals (H x W x D)) | 321 x 321 x 364 mm (12 5/8 x 12 5/8 x 14 5/16") |
| External Dimensions (Including Amp, Drivers, Terminals and Feet (H x W x D)) | 366.5 x 321 x 364 mm (14 7/16 x 12 5/8 x 14 5/16") |
| Weight (unpacked) | 13.4 kg (29 lb 9 oz) |
